ARCHWAY™ PASSAGE™ Parking Garage Discontinued

By Lithonia Lighting

    DLC Standard
  • Overview
  • Specifications

Ideal for use in applications where smart, energy-efficient fixtures are desired. Typical applications include, parking garage, canopy, transportation, school, hospital and exterior retail environments where moisture or dust is a concern. Polycarbonate enclosure protects fixture while remaining easy to service and clean.


Construction

UV-stabilized, injection-molded, impact-resistant, frosted polycarbonate housing with continuous poured-in-place, closed-cell gasket. 20-gauge steel channel and channel cover. Tool-less ballast and wiring access. Fixture design allows for 10-12% uplight.

Optics

UV-stabilized, injection-molded, impact-resistant, clear transparent, polycarbonate lens with aesthetic rib detail (.080" thick). Clear transparent, tamper-resistant, polycarbonate latches standard (8 tamper-resistant screws included). Stainless steel latches also available. Reflectors are precision-formed, high-performance, segmented optics utilizing premium specular aluminum and optimized for both 1- and 2-lamp configurations. Provides 95% reflectivity and warranted for 25 years.

Electrical

Ballasts: Thermally protected, resetting, Class P, HPF, Sound Rating A+. 90°C rated Advance Cool Running™ ballast standard for T5HO. T8 ballast starting temperature is -18°C (0°F) and T5HO starting temperature is -29°C (-20°F).

Lamps: 4100K lamps standard. Secured with rotary locking lampholders for ease of re-lamping and to minimize disconnection due to vibration or incidental contact.

Installation

Stainless steel surface spring-mounting brackets standard (2 included). A variety of stainless steel mounting options available: surface conduit entry on each end and on top, j-box mounting and mounting brackets for suspension with aircraft cable (cable not included). Optional stainless steel V-hooks available for chain hanging (chain not included).

Read More
Read Less
Size 4FT
Shape Rectangular
Light Source Fluorescent
Product Type Linear
Compliance Listing DLC Standard
Environmental Listing IP65, IP66, Wet Location
Regulatory Listing CSA
Dimming Protocol 0-10V
Fixture Wattage 28, 32, 54
Voltage Rating 120, 120-277, 208, 240, 277, 347, 347-480, 480
Color Clear
Mounting Type Surface, Suspended
Series VAP

Read More Read Less
