L7X
- Overview
- Specifications
Recessed incandescent housings for 2x8 new construction. Approved for direct burial in insulation and all ceiling and wiring types.
Construction
L7X: Air-tight, galvanized steel pan with aluminum can and junction box with four built-in ROMEX® clamps and ground wire. Rated for 90°C. Factory-installed captive bar hangers that span up to 24 o.c. and feature stepped shank nail with integral T-bar locks. Two locking screws hold fixture position. Socket clips to trim to ensure proper and consistent lamp position.
Trim retention (clips): Retaining clips riveted to top of reflector hold trim inside housing.
Trim retention (TOR): Two side-mounted torsion springs on the trim and two receiving brackets in the can, ensure a consistently tight fit with the ceiling.
Suitable for ceilings up to 1-1/2" thick.
| Size | 6 IN |
| Shape | Round |
| Light Source | Halogen, Incandescent, LED - Static |
| Product Type | Downlight |
| Environmental Listing | IC |
| Regulatory Listing | CSA, cUL, UL |
| Fixture Wattage | Not Applicable |
| Voltage Rating | 120, 277 |
| Mounting Type | Recessed |
| Series | L7X, L7XLED |
-
Suggested Replacement Products
PRODUCT INFORMATION
-
Spec Sheets
-
Photometry & Revit (BIM)
Use %(percent) to separate search terms.Description Report Design Tools {{photometryItem.Catalog}} Report CLICK HERE to start your request for a BIM Model or IES file. -
Spectral Data Sheets
-
Guideline Specifications
-
BIM Models (Revit)
-
Technical Documents (e.g. Instruction Sheets, MSDS, CAD)
Document Type Document Title Description Updated View Installation Instructions L7X Installation Instruction Sheet L3 Installation Instruction Sheet 11/7/2012 View -
Utility Rebate Search
-
Replacement Parts
Document Type Document Title Description Updated View Replacement Part Spec Sheet 7 Series Vertical Reflectors 7 Series Vertical Reflectors Replacement Part Spec Sheet 9/18/2014 View -
