STS

Square Tapered Steel

By Lithonia Lighting

    Buy America(n)
  • Overview
  • Specifications

Square tapered steel general purpose pole for up to 50-foot mounting heights.


Construction

Shaft: Weldable-grade (ASTM A-595 Grade A) hot-rolled commercial-quality carbon steel tubing with minimum yield of 55,000 psi. Uniform wall thickness of 11-gauge (0.1196") or 7-gauge (0.1793"). Shaft is one piece with a full-length longitudinal high-frequency resistance weld and is square in cross-section having flat sides, rounded corners and a uniform taper of approximately .11" per foot.

Anchor base: Fabricated from hot-rolled carbon steel plate conforming to ASTM A36 that meets or exceeds a minimum-yield strength of 36,000 psi. Base plate and shaft are circumferentially welded top and bottom.

Anchor bolts: Fabricated from carbon steel bar with minimum-yield strength of 55,000 psi. Bolts have an "L" bend on lower end and are galvanized a minimum of 12 inches on the threaded end per ASTM A-153. Each anchor bolt is furnished with two hex nuts and two flat washers.

Grounding: Provision located inside hand hole rim. Grounding hardware is not included (provided by others).

Hand hole: Rectangular, reinforced hand-hole rim having nominal dimensions of 3" x 5" for shafts less than 6.375" square and oval shaped 4" x 6.5" for all other shafts. Steel cover with attachment screws included. Hand hole is located 18" above base.

Hardware: Fasteners are high-strength galvanized or zinc-plated or stainless steel.

Top cap: Removable top cap provided with drill-mount poles.

Base cover: Includes full base cover finished to match pole.

Finish: Must specify finish.

Other

Check out POLESCENTRAL for additional resources and ~13;~10;solutions.

Refer to this link for Light Pole Replacement Parts

Read More
Read Less
Light Source Not Applicable
Product Type Pole
Compliance Listing BAA
Regulatory Listing UL
Mounting Type Anchor Based
Pole Shaft Shape Square
Pole Shaft Style Tapered
Series STS
