SPRTS

Round Tapered Steel Sport Lighting

By Lithonia Lighting

  • Overview
  • Specifications

Round tapered steel sports lighting pole with 40- to 80-foot mounting heights. 60-foot and longer are two section poles.


Construction

Shaft: Pole shaft sections are high-strength low-alloy steel conforming to ASTM A572 Grade 65 or ASTM A595 Grade A. Cross-section is round or 16-sided with a 4" bend radius. Each pole is a constant tapered hollow steel section up to 55 feet in length with a minimum 1-1/2 times diameter slip joint as standard for two section pole. Shaft plate is single thickness without laminations.

Anchor base: Fabricated from hot-rolled carbon steel plate that conforms to ASTM A36 or ASTM A572 Grade 42. Base plate and shaft are circumferentially welded top and bottom.

Anchor bolts: Fabricated from carbon steel bar with minimum-yield strength of 55,000 psi. Bolts have an "L" bend on lower end and are galvanized a minimum of 12 inches on the threaded end per ASTM A-153. Each anchor bolt is furnished with two hex nuts and two flat washers.

Grounding: Provision located inside hand hole rim. Grounding hardware is not included (provided by others).

Hardware: Fasteners are high-strength galvanized or zinc-plated or stainless steel.

Hand hole: Oval shaped, reinforced hand-hole rim having a nominal dimension of 4" x 6.5". Steel cover with attachment screws included. Hand hole is located 18" above base.

Top cap: Removable top cap provided with all drill-mount poles.

Finish: Must specify finish.

Other

Check out POLESCENTRAL for additional resources and solutions.

Refer to this link for Light Pole Replacement Parts

Read More
Read Less
Light Source Not Applicable
Product Type Pole
Regulatory Listing UL
Color Black, Bronze, Gray, Silver, White
Mounting Type Pole Mount
Pole Shaft Shape Round
Pole Shaft Style Tapered
Series SPRTS
