UN-NY

Heavy-Duty Channels

By Lithonia Lighting

  • Overview
  • Specifications

Lithonia Catalog Number
UNS 2 17 MVOLT GEB10IS NY

UNS 2 25 MVOLT GEB10IS NY
UNS 2 32 MVOLT GEB10IS NY
TUNS 2 32 MVOLT 1/4 GEB10IS NY
UNS 2 96 120 GEB NY
UNS 2 48HO 120 CW20 GEB NY
UNS 2 96HO 120 CW20 GEB NY
UNS 1 96 120 GEB NY


Ideal where high brightness and high illumination levels are required such as retail, industrial and warehouse applications.

Fixtures assembled with snap and screwed together components. Available in a variety of lengths and lamp configurations. Gripper-back design for superior strength and rigidity.


Construction

Constructed to comply with New York City electric code. Made in USA. Sturdy channel cover secured by quarter-turn latch for tool-less access to wireway. Screw-on endplates.

Finish: Five-stage iron-phosphate pretreatment ensures superior paint adhesion and rust resistance. Finish is high-gloss baked white polyester.

Electrical

Thermally protected, resetting, Class P, HPF, UL listed, CSA Certified ballast is standard. Energy saving and electronic ballasts are sound rated A. Fixture is suitable for damp locations. AWM, TFN or THHN wire used throughout, rated for required temperatures.

Installation

For unit or row installation, surface or suspended mounting. Channel connector furnished standard.

Read More
Read Less
Size 2FT, 4FT, 8FT
Shape Rectangular
Light Source Fluorescent
Product Type Strip Light
Environmental Listing Damp Location
Regulatory Listing UL
Fixture Wattage 17, 25, 32, 59, 60
Voltage Rating 120, 120-277, 277
Color White
Mounting Type Surface, Suspended
Series TUNS, UNS, WGCUN

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET UNS NY New York City; T8 T8HO Specsheet, Heavy-duty Channels 3/24/2021 View
