SSF

Square Straight Fiberglass

By Lithonia Lighting

  • Overview
  • Specifications

Square straight fiberglass general purpose pole for up to 30-foot mounting heights.


Construction

Shaft: Reinforced composite shaft incorporating "E" type fiberglass and pigmented, UV-inhibiting, thermosetting polyester resin. Shaft is formed by the pultrusion process with fiberglass strands traversing the length of the pole.

Anchor base: Heavy-duty metal base plate is permanently bonded to the outside of the fiberglass shaft.

Anchor bolts: Fabricated from carbon steel bar with minimum-yield strength of 55,000 psi. Bolts have an "L" bend on lower end and are galvanized a minimum of 12 inches on the threaded end per ASTM A-153. Each anchor bolt is furnished with two hex nuts and two flat washers.

Hand hole: Standard 2-1/2" x 5" hand hole opening with non-metallic oval-shaped covers secured with vandal-resistant stainless steel 1/4" socket-head screws.

Hardware: Fasteners are high-strength galvanized or zinc-plated or stainless steel.

Top cap: Removable top cap provided with drill-mount poles.

Base cover: Includes full-base cover finished to match pole.

Finish: Must specify finish.

Other

Check out POLESCENTRAL for additional resources and solutions.

Read More
Read Less
Product Type Pole
Regulatory Listing UL
Mounting Type Anchor Based
Pole Shaft Shape Square
Pole Shaft Style Straight
Series SSF
