Incito™ 6" Square Downlight

High Center Beam LED Downlight

By Gotham Lighting

    Buy America(n) Option Available
  • Overview
  • Specifications
OPTICS
Incito™ high intensity distribution provides narrow field angles to create sharp contrast with crisp highlights and deep shadows for a dramatic layer of light.
  • Functions: Open downlight
  • Beam angles: Ranging from 20° to 70°
  • Trim options: Self-flanged or flangeless
PERFORMANCE
Our high-performing downlights provide the quality of light needed to create multiple layers of light within a space.
  • Bounding Ray™ technology eliminates flash for superior glare control
  • Lumens: 2,000-8,500 LM
  • Listings: CSA, Wet Location, Buy American
  • Driver capabilities: Up to 5 different driver options from 0-10v to DMX
  • Controls: nLight® wired lighting controls
  • Emergency Battery Backup
DESIGN
For wherever you specify downlights, we offer an ample array of installation options, trims, sizes, and colors allowing for a complete custom design.
  • Reflector finishes: Semi-specular and matte diffuse
  • Trims: Interchangeable open trim
  • Ceiling types: Metal, wood, drywall, suspended grid ceilings
Read More
Read Less
Aperture Size 6 IN
Shape Square
Light Source LED - Static
Lumens 2500 LM, 3000 LM, 3500 LM, 4000 LM, 4500 LM, 5000 LM, 5500 LM, 6000 LM, 6500 LM, 7000 LM, 7500 LM, 8000 LM, 8500 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K
CRI 90
Product Type Downlight
Compliance Listing BAA, Chicago Plenum
Environmental Listing Non-IC, Wet Location
Regulatory Listing CSA
Dimming Protocol 0-10V, DALI, DMX
Voltage Rating 120, 277, 347
Trim Style Open
Color Black, Clear, Gold, Pewter, Wheat, White
Special Applications Education, Government, Hospitality, House of Worship, Offices & Banks, Residential, Retail
Function Downlight
Product Series Incito
Series ICO

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET 6" LED Square Open Downlight ICO 6" Open Square Downlight 11/9/2022 View

    Create Submittal Spec Sheet

  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.
  • Spectral Data Sheets

  • Guideline Specifications

  • BIM Models (Revit)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions ICO & ICO SQ MOUNTING FRAME Installation Instructions CJ5200912.pdf ICO 6" Housing View
    Installation Instructions ICO_ICO SQ_TRIM_CJ5200913 ICO 6" Trim View
    User Manual DMX with RDM Manual.pdf DMX with RDM Manual 9/14/2021 View
