EVO® 8" Round Vandal Resistant

General Illumination LED Downlight for Vandal and Tamper Resistance

By Gotham Lighting

    Buy America(n)
  • Overview
  • Specifications
OPTICS
EVO® batwing distribution provides a uniform, wide angled general illumination on horizontal and vertical surfaces to create smooth edges and an even layer of light without hot spots or rings.
  • Cutoff: 45°
  • Functions: Open downlight
  • Beam angles: Very narrow, narrow, medium, medium wide, wide
  • Trim options: Glass or polycarbonate lens
PERFORMANCE
Our high-performing downlights provide the quality of light needed to create multiple layers of light within a space.
  • Bounding Ray™ technology eliminates flash for superior glare control
  • Lumens: 2,000-3,000 LM
  • Listings: CSA, Wet Location, IP55, IP65
  • Driver capabilities: Up to 10 different driver options from 0-10v to DMX
  • Controls: nLight® wired and wireless lighting controls
  • Emergency Battery Backup
DESIGN
For wherever you specify downlights, we offer an ample array of installation options, trims, sizes, and colors allowing for a complete custom design.
  • Ceiling types: Metal, wood, drywall, suspended grid ceilings
Read More
Read Less
Aperture Size 8 IN
Shape Round
Light Source LED - Static
Lumens 2000 LM, 2500 LM, 3000 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, 5000 K
CRI 85, 90
Product Type Downlight
Compliance Listing BAA
Environmental Listing IP65, Wet Location
Regulatory Listing CSA
Dimming Protocol 0-10V, DALI, Digital, DMX, Forward Phase
Voltage Rating 120, 277, 347
Trim Style Cone, Lensed
Color Black, Bronze, Clear, Gold, Gray, Pewter, Silver, Wheat, White
Mounting Type Recessed
Special Applications Behavioral Health, Confinement, Education, Enclosed & Gasketed, Sports and Recreation, Transportation, Vandal Resistant
Function Downlight
Product Series EVO
Series EVO8VR

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET EVO8VR.pdf EVO 8" Vandal Downlight 4/4/2022 View

    Create Submittal Spec Sheet

  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.
  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions EVO_RD_FRAME_INSTALL_CJ5201006_pdf.pdf EVO 4"/6"/8" Housing 10/18/2021 View
    Installation Instructions VR_GVRT_EVO VR_CJ520360 EVO 6"/8" Vandal Resistant Lightshield Trim View
