SFOD 7 ODP

Outdoor Snap-Fit, 360 Low Bay, On Off Dim, Photocell

By SensorSwitch

  • Overview
  • Specifications
The SFD 7 ODP Series sensors provide both motion and daylight based control of a 0-10 VDC dimmable outdoor or wet location luminaire. The SFD 7 ODP can both dim and turn on/off its connected lighting.

For motion detection, the sensor utilizes 100% digital passive infrared (PIR) technology that is tuned for walking size motion while preventing false tripping from the environment. The unit's integrated photocell enables additional energy savings during daytime periods when there is sufficient daylight.
Features:
  • 100% digital PIR detection - excellent RF immunity
  • Integrated photocell
  • 0-10 VDC output for dimming
  • Snap-in style embedded mounting
  • Gasketed for outdoor operation
  • Compatible with 0-10 VDC dimmable ~9;~9;~9; ballasts and LED drivers
  • Adjustable time delays, max/min dim ~9;~9; levels and ramp rates
  • Programming button accessible without opening sensor or removing gasketing
  • No field calibration or sensitivity adjustments required
  • Non-volatile settings memory
  • Convenient test mode
  • Green LED indicator
Read More
Read Less
Control Device Type Occupancy Sensor
Mounting Type Fixture Embedded, Recessed
Control Protocol 0-10V
Product Type Sensor
Color Black, White
Series SFOD
Application Type Education, Government, Healthcare, Hospitality, House of Worship, Manufacturing, Offices & Banks, Power & Gas, Residential, Retail, Sports and Recreation, Transportation, Warehouses

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    SPEC SHEET SFOD 7 ODP SFOD Low Voltage, Micro Outdoor Fixture/Embedded Mount Occupancy Sensors Spec Sheet. View

  • Photometry & Revit (BIM)

  • Spectral Data Sheets

  • Guideline Specifications

  • Revit Component Files (Non-Illuminated)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions IC14-003 SBGR.pdf MSOD Low Voltage, Micro Outdoor Fixture/Embedded Mount Occupancy Sensors Programming Sheet. View
