ICO4WTRC Adjustable Cylinder

ICO 4" LED Round Tilt and Rotate Wall Mount Cylinder

By Gotham Lighting

    Energy Star®Buy America(n)
  • Overview
  • Specifications
  • High Center Beam Candlepower (CBCP) and narrow field angle create sharp contrast with crisp highlights and deep shadows
  • Lumen packages: 500/750/1000/1500/2000/2500/3000/3500/4000/4500/5000
  • Symmetrical beam angles available: 10°, 15°, 20°, 25°, 30°, 35°, 40°, 45°, 50°, 60°, 65°
  • Bounding Ray™ optical design
  • 45° cutoff to source and source image
  • Fully serviceable and upgradeable lensed LED light engine
  • 70% lumen maintenance at 60,000 hours
  • 2.5 SDCM; 85 CRI typical, 90+ CRI optional
  • Fixtures are damp location standard; wet location option (WL or WLL)
  • 20 standard colors in textured and gloss finish; custom or RAL colors also available
  • Adjustable wall mount tilts to +40° and -20° with +/-40° rotation from vertical
  • IP66 rated for outdoor environments
Read More
Read Less
Aperture Size 4 IN
Shape Round
Light Source LED - Static
Lumens 500 LM, 750 LM, 1000 LM, 1500 LM, 2000 LM, 2500 LM, 3000 LM, 3500 LM, 4000 LM, 4500 LM, 5000 LM
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, 5000 K
CRI 90
Product Type Cylinder
Compliance Listing BAA, ENERGY STAR®
Environmental Listing IP66, Wet Location
Regulatory Listing CSA
Dimming Protocol 0-10V, DALI, Digital, DMX, Forward Phase
Fixture Wattage 14.3, 18.8, 24.3, 31.9, 33.6, 40.2, 47.1, 54, 6.52, 7.34, 9.48
Voltage Rating 120, 120-277, 277, 347, MVOLT
Trim Style Cone, Open
Color Almond, Black, Blue, Bronze, Clear, Gold, Gray, Green, Ivory, Pewter, Red, Silver, Wheat, White
Mounting Type Surface
Special Applications Education, Government, Hospitality, House of Worship, Offices & Banks, Residential, Retail
Function Adjustable
Product Series Incito
Series ICO4WTRC

Read More Read Less
