Holophane
Holophane

PHS High Bay

Phuzion™ LED High Bay with Uplight Single or Twin
    DLC Standard
  • Overview
  • Specifications
Read More
Read Less
Light Source LED - Static
Lumens 12,000 LM, 15,000 LM, 18,000 LM, 24,000 LM, 30,000 LM, 35,000 LM, 40,000 LM, 45,000 LM
CCT / LED Color 3000 K, 3500 K, 4000 K, 5000 K
CRI 70, 80, 90
Compliance Listing DLC Standard
Environmental Listing Dry Location
Regulatory Listing cCSAus
Product Type High Bay
Control Platform nLight AIR G2, nLight Wired, Sensor Switch Standalone
Dimming Protocol 0-10V
Voltage Rating 120, 120-277, 208, 240, 277, 347, 347-480, 480
Mounting Type Fixture Attached, Pendant, Surface
Mounting Location Ceiling
Primary Material Aluminum
Architectural Style Traditional
Series PHS

Read More Read Less

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet PHS_ Phuzion LED High Bay with Uplight 12/3/2024 View
    Spec Sheet PHST_ Phuzion Twin LED High Bay with Uplight 12/3/2024 View
    Spec Sheet RPHS_ Phuzion Remote LED High Bay with Uplight 12/3/2024 View

  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.
    Clear Filters

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.

  • Spectral Data Sheets

    >> CLICK HERE to Download Spectral Data FAQs

    Document Type Document Title Description Updated View
    Spectral Data Sheet SpectralDataSheet_PHS_40K_80CRI.pdf PHS 40K 80CRI 4/15/2024 View

  • Guideline Specifications

  • Revit Component Files (Non-Illuminated)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions 02 - IN-48-H QDH - Quick Disconnect Hanger Instruction Sheet (English) 2/22/2021 View
    Installation Instructions 04-qdh-installation-instructions-in-48-d_fr-CA.pdf QDH - Feuille d'instructions du cintre à déconnexion rapide (French) 12/6/2024 View
    Installation Instructions 06 - qdh-installation-instructions-in-48-d_ QDH - Hoja de instrucciones del soporte de desconexión rápida (Spanish) 12/6/2024 View
    Installation Instructions IM-308 Twin Phuzion™ LED High Bay with Uplight (PHST) Installation Instructions 8/25/2015 View
    Installation Instructions IM-369-F Phuzion™ LED High Bay with Uplight (PHS) Installation Instructions 1/10/2022 View
    Installation Instructions IM-387-B Remote Phuzion™ LED High Bay with Uplight (RPHS) Installation Instructions 8/25/2022 View
    Material Safety Data Sheet 14 - IE30WCPHE or IE30WCPHER MSDS MSDS Data Sheet for IE30WCPHE or IE30WCPHER Batteries 7/31/2021 View

  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1: Enter the Zip Code or Select the State and Utility

    Step 2: Ensure that the correct Product Category is selected if there is more than one option


  • Replacement Parts

    Document Type Document Title Description Updated View
    Replacement Part Spec Sheet PHS Replacement Parts PHS Replacement Drivers, Lenses, SPD, and Misc. Parts for GEN1 and Current Generation. 12/12/2022 View
    Replacement Part Spec Sheet PHST Replacement Parts PHST Replacement Drivers, Lenses, SPD, and Miscellaneous Parts for GEN1 and Current Generation. 12/12/2022 View
    Replacement Part Spec Sheet RPHS Replacement Parts RPHS Replacement Drivers, Lenses, SPD, and Miscellaneous Parts for GEN1 and Current Generation. 12/12/2022 View
