Contractor Select LBR4 Round Retrofit Series

Most popular and readily available LBR4 configurations for your everyday lighting needs

By Lithonia Lighting

    Switchable Lumens  Switchable CCTs  Energy Star®
  • Overview
  • Specifications
Lithonia Basic Retrofit (LBR) is everything you need in a retrofit downlight at an affordable price. Whether it’s the seamless install-from-below design, abundant energy savings, or maintaining glare-free aesthetics, LBR is the perfect solution for any renovation or new construction project. To top it off, LBR has a broad offering of aperture sizes, drivers, accessories and switchable CCTs and lumens.

To view additional LBR configurations click here.
Read More
Read Less
Size 4 IN
Shape Round
Light Source LED - Static
Dynamic Feature Switchable White
Lumens 1000 LM, 1500 LM, 2000 LM, Switchable
CRI 80
Product Type Retrofit Kit
Compliance Listing ENERGY STAR®
Environmental Listing Damp Location, IC
Regulatory Listing CSA, UL
Dimming Protocol 0-10V, Electronic Low Voltage, Triac
Fixture Wattage 25.6
Voltage Rating 120-277
Trim Style Open, Single Wallwash
Mounting Type Recessed
Series LBR4
Days To Ship 2 or Less

Read More Read Less
