KL
- Overview
- Specifications
For use in site walls or as stair lighting.
Construction
Housing: One-piece, cast-aluminum housing (alloy contains less than 0.2% copper) with integral splice compartment (46 cu. in.); four 3/4" NPT conduit entries. Lens is one-piece, injection-molded, UV-stabilized polycarbonate, .125" minimum thickness. Tooled-in, stippled texture on non-optical portions. Die-cut, closed-cell EPDM gasket. Housing is shipped separately from lens/reflector/power module. Stainless steel, captive, Philips-type fasteners (tamper-resistant fasteners also provided). Standard lens finish is dark bronze enamel (painted on both inside and outside of non-optical portion). Black, white and natural aluminum finishes also available. Housing finish is clear polyester powder for corrosion protection. Recessed concrete cast in place is standard; optional mountings available.
Optics
Reflectors are anodized, hydroformed aluminum. Two distributions available: A (for uniform symmetrical area lighting) and D (for left or right directional-throw area lighting, featuring a unique bi-adjustable socket assembly that can be field-adjusted up or down to provide maximum light distribution on stairway plane).
Electrical
All ballasts are 100% factory-tested. Electrical components are unitized on removable power module. Positive-locking disconnect on primary and secondary circuits. Medium-base porcelain socket, 4KV pulse rated.
Shape | Rectangular |
Light Source | HID - Metal Halide, Incandescent |
Lumens | 5500 LM, 6000 LM |
CCT / LED Color | 3200 K, 3500 K |
CRI | 70, 88 |
Product Type | Wallpack |
Regulatory Listing | UL |
Voltage Rating | 120, 208, 240, 277, 347 |
Color | Beige, Black, Silver, White |
Mounting Type | Recessed, Surface |
Series | KL |
